    Product Details:

    Place of Origin: Germany
    Brand Name: BTH BOLTE
    Certification: CE
    Model Number: VBZ

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Uunit
    Price: Negotiation
    Packaging Details: Packed in carton firstly, and then reinforced with wooden case for outer packing
    Delivery Time: 15 working days after received your payment
    Payment Terms: T/T, Western Union
    Supply Ability: 30 units per month
    Contact Now
    Detailed Product Description
    Stud Diameter: Ø 2-8 Mm Stud Length: 6-50 Mm
    Stud Type: Welding Elements With Flange Feeding Capacity: Up To 50 Studs/minute
    Feeder Bowl Diameter: 230 Mm Compressed Air Connection: 6 Bar

    Automatic Stud Feeder VBZ for the Fully Automatic Feeding of Welding Elements



    BTH BOLTE Automatic Stud Feeder VBZ





        The VBZ is a feeder for the fully automatic feeding of welding elements into an automatic stud welding head or an automatic stud welding gun. It is suitable for welding elements with flange, the modification for welding elements without flange or special welding elements (e.g.insulation nails) is possible on inquiry.





    Stud diameter Ø 2-8 mm
    (other Ø on inquiry)
    Stud length 6-50 mm
    (other lengths on inquiry)
    Stud type welding elements with flange
    (other stud types on inquiry)
    Feeding capacity up to 50 studs/minute
    (depending on stud diameter and length)
    Maximum filling quantity 6 kg
    Feeder bowl diameter 230 mm
    Compressed air connection 6 bar
    Mains supply 230 V, 50 Hz (optional: 115 V, 50 Hz)
    Mains plug earth contact plug according to DIN 49441
    Dimensions (WxHxL) 195x265x410 mm
    Weight (without cable) 23,5 kg



    • suitable for welding elements with flange.
    • feeding capacity continuously adjustable
    • air pressure adjustable for optimal adaptation to different welding elements
    • improved stud separating and feeding through impact pressure sensor
    • quiet, failure-free stud transport
    • simple handling
    • quick and simple retooling (equipment kits for different welding elements/stud diameters)
    • one-piece cover as protection against welding spatters, dirt and noise (sorting, separating and feeding system in one case)
    • feeding bowl made from high-value stainless steel (abrasion-resistant and rust-proof)
    • all connectors placed on the front plate for optimal accessibility
    • clear-sighted cover for easy monitoring of fill level
    • low air consumption
    • applicable with all automatic welding heads and guns
    • interface for data exchange with higher ranked control systems
    • high service life through high-grade mechanical components
    • robust, powder-coated metal housing
