LBSaccu 50 Stainless Steel Capacitor Discharge Stud Welding Machine Indicated By LCD Display

LBSaccu 50 Stainless Steel Capacitor Discharge Stud Welding Machine Indicated By LCD Display

    • LBSaccu 50 Stainless Steel Capacitor Discharge Stud Welding Machine Indicated By LCD Display
    • LBSaccu 50 Stainless Steel Capacitor Discharge Stud Welding Machine Indicated By LCD Display
    • LBSaccu 50 Stainless Steel Capacitor Discharge Stud Welding Machine Indicated By LCD Display
    • LBSaccu 50 Stainless Steel Capacitor Discharge Stud Welding Machine Indicated By LCD Display
  • LBSaccu 50 Stainless Steel Capacitor Discharge Stud Welding Machine Indicated By LCD Display

    Product Details:

    Place of Origin: Germany
    Brand Name: LBH BOLTE
    Certification: CE
    Model Number: LBSaccu 50

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 units
    Price: Negotiation
    Packaging Details: Packed in carton firstly, and then reinforced with wooden case for outer packing
    Delivery Time: 15 working days after received your payment
    Payment Terms: T/T, Western Union
    Supply Ability: 30 units per month
    Contact Now
    Detailed Product Description
    Max. Welding Diameter: Ø 6 Mm Welding Material: Steel, Stainless Steel
    Capacitance: 47000 μF Charging Voltage: 60 - 200 V
    Welding Time: 1 - 3 MS Number Of Welds/battery Charge: M3/Ø3: 2800 M4/Ø4: 1500 M5/Ø5: 1100 M6/Ø6: 650
    Battery (capacity/voltage): 2 X 7,5 Ah/12 V Battery Life: 1000 Charging Cycles
    Battery Charging Time: 3 Hours External Power Adapter (for Charging/welding From Mains): 100 - 240 V, 50/60 Hz, 4000 MA
    Dimensions (B X L X H): 195 X 302 X 270 Mm Gewicht: 9,9 Kg
    Article Number: B-90-30-2052 Suitable Welding Guns: PKM-1B, PIM-1B
    Highlight:

    capacitor welding machine

    ,

    stud welding unit

    LBSaccu 50 Stainless Steel Capacitor Discharge Stud Welding Machine Indicated By LCD Display

    BTH BOLTE LBSaccu 50 Battery Powered Stud Welding Unit

    Capacitor Discharge Stud Welding Machine



    Whatsapp: +86 13818731663
    Wechart: 630531309



        The battery powered stud welding unit LBSaccu 50 is designed for capacitor discharge stud welding with up to 200V charging voltage. The unit welds steel and stainless steel studs up to M6 resp. Ø6 reliable in process.

        The battery operation enables mobile use without electrical power supply. The integrated battery offers a very high capacity. With a life period of approx. 1000 charging cycles it is extremely long-lasting. Alternatively (e.g. when the battery is empty), the unit can be operated at every power socket.

        The LBSaccu 50 is very light and very compact (195 x 302 x 270 mm). It convinces through easy operation and high welding quality. Through the electronically clocked inverter charging board short charging times and thus quick welding sequences are accomplished. The robust construction ensures high reliability and high power-on time. All functions are indicated by the high-grade LCD display. The charging voltage is continuously adjustable by the rotary knob on the front.





    Max. welding diameter Ø 6 mm
    Welding material steel, stainless steel
    Capacitance 47000 μF
    Charging voltage 60 - 200 V
    Welding time 1 - 3 mS
    Number of welds/battery charge M3/Ø3: 2800
    M4/Ø4: 1500
    M5/Ø5: 1100
    M6/Ø6: 650
    Battery (capacity/voltage) 2 x 7,5 Ah/12 V
    Battery life 1000 charging cycles
    Battery charging time 3 hours
    External power adapter
    (for charging/welding from mains)
    100 - 240 V, 50/60 Hz, 4000 mA
    Dimensions (B x L x H) 195 x 302 x 270 mm
    Gewicht 9,9 kg
    Article number B-90-30-2052
    Suitable welding guns PKM-1B, PIM-1B



    • lightweight
      • low weight for high mobility
    • small and compact
      • dimensions: 195 x 302 x 270 mm
    • LCD-Display
      • easy to read
      • display of adjusted charging voltage
      • display of welds performed (welding counter resettable)
      • display of welds still possible
      • charging state indicator (colour changing of the display)
    • very easy operation
      • charging voltage continuously adjustable
      • one-button operation by robust rotating pressure switch
    • applicable with stud welding gun PKM-1b
      • for welding threaded studs, non-threaded studs, internally threaded studs, earth plugs and insulation nails
      • welding material: steel, stainless steel
    • applicable with stud welding gun PIM-1b
      • for welding cupped head pins
      • welding material: steel, stainless steel
    • powerful
      • perfect welds of very high strength
      • very high battery capacity
    • long-lasting high-end lithium battery
      • battery life approx. 1000 charging cycles!
    • full battery charge from mains in only 3 hours
    • easy, tool-less change of battery
    • efficient energy management
      • automatic stand-by mode (after 30 minutes)
      • automatic shut-down (after 60 minutes)
    • electronically clocked inverter charging board
      • ensure short charging times and thus quick welding sequences
      • ensure energy-efficient charging of capacitors
    • mains operation
      • Alternatively (e.g. when the battery is empty), the unit can be operated at every power socket.
    • utmost safety
      • electronic function control
      • self-diagnosis system
      • automatic function test
      • repeat cycle lock to avoid welding on already welded studs
      • battery deep discharge protection
    • automatic switch-off in case of excess temperature
    • protection of the unit in case of a fault on welding/control line cable and solenoid
    • high quality, robust unit body for harsh building site conditions



    All battery powered capacitor discharge stud welding units at a glance





        LBSaccu 50 LBSaccu 50s LBSaccu 75 LBSaccu 75s LBSaccu 90 LBSaccu 90s
    Max. welding diameter (mm) 6 6 8 8 10 10
    Welding material steel, stainless steel steel, stainless steel, aluminium, brass steel, stainless steel steel, stainless steel, aluminium, brass steel, stainless steel steel, stainless steel, aluminium, brass
    Capacitance (μF) 47000 47000 66000 66000 88000 88000
    Charging voltage (V) 60-200 60-200 60-200 60-200 60-200 60-200
    Welding time (mS) 1-3 1-3 1-3 1-3 1-3 1-3
    Number of welds/battery charge M3/Ø3: 2800
    M4/Ø4: 1500
    M5/Ø5: 1100
    M6/Ø6: 650
    M3/Ø3: 2800
    M4/Ø4: 1500
    M5/Ø5: 1100
    M6/Ø6: 650
    M3/Ø3: 2800
    M4/Ø4: 1500
    M5/Ø5: 1100
    M6/Ø6: 650
    M8/Ø8: 400
    M3/Ø3: 2800
    M4/Ø4: 1500
    M5/Ø5: 1100
    M6/Ø6: 650
    M8/Ø8: 400
    M3/Ø3: 2800
    M4/Ø4: 1500
    M5/Ø5: 1100
    M6/Ø6: 650
    M8/Ø8: 400
    M10: 250
    M3/Ø3: 2800
    M4/Ø4: 1500
    M5/Ø5: 1100
    M6/Ø6: 650
    M8/Ø8: 400
    M10: 250
    Battery (capacity/voltage) 2 x 7,5 Ah/12 V 2 x 7,5 Ah/12 V 2 x 7,5 Ah/12 V 2 x 7,5 Ah/12 V 2 x 7,5 Ah/12 V 2 x 7,5 Ah/12 V
    Battery life 1000 charging cycles 1000 charging cycles 1000 chargin cycles 1000 charging cycles 1000 charging cycles 1000 charging cycles
    Battery charging time 3 hours 3 hours 3 hours 3 hours 3 hours 3 hours
    Error diagnosis systems
      Excess temperature x x x x x x
      Damage on welding/control cable x x x x x x
      Damage on solenoid x x x x x x
    External power adapter (for charging/welding from mains) 100-240 V, 50/60 Hz, 4000 mA 100-240 V, 50/60 Hz, 4000 mA 100-240 V, 50/60 Hz, 4000 mA 100-240 V, 50/60 Hz, 4000 mA 100-240 V, 50/60 Hz, 4000 mA 100-240 V, 50/60 Hz, 4000 mA
    Thermic controlled ventilator x x x x x x
    Robust, powder-coated metal housing x x x x x x
    Dimensions
      Width (mm) 195 195 275 275 195 195
      Height (mm) 302 302 302 302 302 302
      Length (mm) 270 270 270 270 270 270
      Weight (kg) 9,9 10 10,4 10,5 11,3 11,4
    Control cable socket for welding guns 7-pin 7-pin 7-pin 7-pin 7-pin 7-pin
    Suitable welding guns
      PKM-1B x o x o x o
      PHM-1A   x   x   x
      PIM-1B o o o o o o
    x = Standard, o = Option
